CHANNEL 400x2000 CENTER OUTLET - (674FK020-10BA)

Part Of the Series: Channel-Liquid membrane

Type no.: 674FK020-10BA

EAN no.: 5705499131413

Size: 400x2000

Product Specification
Floor Concrete / Tiled / Resin
Material AISI 304
Material (EN) EN 1.4301
Membrane Type Liquid Membrane
Minimum Height (mm) 170
Outlet Box No
Outlet Diameter (mm) 160
Outlet Direction Vertical
Outlet Placement Center
Shape Rectangular
Size (mm) 400x2000
Weight (kg) 24,56
