SHOWER CHANNEL WATERLINE 800, SET - (378.080.056.4B)
×
![]()
Part Of the Series: Shower channel-Liquid membrane
Type no.: 378.080.056.4B
EAN no.: 5705499138191
NRF no.: 3394685
LVI no.: 3304479
Size: 50x800
SHOWER CHANNEL WATERLINE 800, SET
-With COPENHAGEN grating
-Floor: concrete and tiled
-Frame: rectangular
-Outlet: Ø75mm horizontal, inclusive water trap
-Stainless steel: AISI304/EN1.4301
| Product Specification | |
|---|---|
| Floor | Concrete / Tiled |
| Load Class EN1253 | K3 |
| Material | AISI 304 |
| Material (EN) | EN 1.4301 |
| Membrane Type | Liquid Membrane |
| Outlet Box | No |
| Outlet Diameter (mm) | 75 |
| Outlet Direction | Horizontal |
| Outlet Placement | End |
| Shape | Rectangular |
| Size (mm) | 50x800 |
| Weight (kg) | 3,54 |
-
Downloads
-
Approval Information
For approval information, please refer to the below approval certificates.
