PENETRATION WITH FLANGE - (868.140.125FS)
Part Of the Series: Penetration-welding flange-steel
Type no.: 868.140.125FS
EAN no.: 5705499139648
PENETRATION WITH FLANGE
-Diameter: Ø125mm
-With SI sealing
-Deck: steel
-Stainless steel: AISI316L/EN1.4404
Product Specification | |
---|---|
Deck | Steel |
EC/MED (Bulkhead) | A0-A60 |
EC/MED (Deck) | A0-A60 |
Length (mm) | 100 |
Material | AISI 316L |
Material (EN) | EN 1.4404 |
Minimum Height (mm) | 240 |
Outlet Diameter (mm) | 125 |
Weight (kg) | 1,36 |
-
Downloads
-
Approval Information
For approval information, please refer to the below approval certificates.
