PENETRATION WITH SLEEVE - (866.025.200.10F)
×
![]()
Part Of the Series: Penetration-welding sleeve-steel
Type no.: 866.025.200.10F
EAN no.: 5705499140774
PENETRATION WITH SLEEVE
-With SI sealing
-Diameter: Ø200mm
-Deck: Steel
-Stainless steel: AISI304/EN1.4301
| Product Specification | |
|---|---|
| Deck | Steel |
| EC/MED (Bulkhead) | A0-A60 |
| EC/MED (Deck) | A0-A60 |
| Length (mm) | 250 |
| Material | AISI 304 |
| Material (EN) | EN 1.4301 |
| Outlet Diameter (mm) | 200 |
| Weight (kg) | 5,24 |
-
Downloads
-
Approval Information
For approval information, please refer to the below approval certificates.
HACCP Food Safety Programme - Europe
DNV - MEDB000016W, Rev7, Penetrations with SI sealing DNV - TAP0000023-rev5, Sanitary discharge pipes KR - Type Approval CPH42135-PE001 ClassNK - Type866, TA21159E(N)_21FPA11DA RINA -MAC285119XG EuroPipe MARINE - R4547 NATO CODIFICATION SYSTEM ABS - 23-2329630-PDA Lloyds Register LR22419510TA_02 Achilles Certificate - 46702-22 Bureau Veritas, 02375-I0 Pipes & Fittings
