UPPER PART - (710.423.000 S)
×
Part Of the Series: Upper part-Liquid membrane-300
Type no.: 710.423.000 S
EAN no.: 5705499138832
VVS no.: 153018528
Size: 300x300
UPPER PART
-Floor: concrete and tiled
-Liquid membrane, frame: 300x300mm
-Stainless steel: AISI316L/EN1.4404
Product Specification | |
---|---|
Floor | Concrete / Tiled |
Material | AISI 316L |
Material (EN) | EN 1.4404 |
Number of Screw Holes | 0 |
Outlet Diameter (mm) | 160 |
Shape | Square |
Size (mm) | 300x300 |
Weight (kg) | 4,42 |
-
Downloads
-
Approval Information
For approval information, please refer to the below approval certificates.
