CHANNEL 150x1000 CENTER OUTLET - (674CH010-05BA)

Part Of the Series: Channel-Liquid membrane

Type no.: 674CH010-05BA

EAN no.: 5705499130805

NRF no.: 3397113

Size: 150x1000

Product Specification
Floor Concrete / Tiled / Resin
Material AISI 304
Material (EN) EN 1.4301
Membrane Type Liquid Membrane
Minimum Height (mm) 152
Outlet Box No
Outlet Diameter (mm) 110
Outlet Direction Vertical
Outlet Placement Center
Shape Rectangular
Size (mm) 150x1000
Weight (kg) 8,82
